Heatilator

Heatilator Heirloom 50 Gas Fireplace

Model: HEIR50H/T-IFT

Product only. Installation and materials are additional. Venting, finishing, optional accessories, delivery, and taxes are not included. Your complete project will be quoted separately.

Request a Quote

Selections are preferences for your quote. Compatibility, availability, and additional charges will be confirmed.

Heatilator

About this model

Heirloom gives a traditional gas fire a large, tall viewing area and a flush-hearth appearance. A selected brick interior frames the log fire, with front styles chosen to suit the room.

This page covers Heirloom 50 (HEIR50H/T-IFT). Natural gas and propane configurations must match the appliance rating plate. Request a quote for the selected equipment and installation.

Specifications
Manufacturer model
HEIR50H/T-IFT
Fuel
Natural gas or propane, with the listed configuration or certified conversion
Natural gas input at 0–2,000 ft
36,000–65,000 BTU/h
Propane input at 0–2,000 ft
30,250–57,500 BTU/h
Viewing Area
49-7/8 x 40-1/16"
Framing Depth — planning only
24"
Framing Height — planning only
65"
Manuals and documents
Standard features

Traditional log set, ceramic viewing glass and IntelliFire Touch touchscreen remote.

One factory-selected Traditional or Herringbone interior.

Required components

Choose the matching Herringbone or Traditional factory model and a compatible decorative barrier front.

Listed vent pipe, termination, supports and firestops must suit the actual route. Gas supply, electrical work, framing and compliant finishing are separately quoted.

Required Decorative Interior panels: Herringbone; Traditional. Choose the Herringbone or Traditional factory configuration. One matching interior is included with that configuration.

Required Fronts and Doors: Firescreen — Black; Firescreen — New Bronze; Firescreen Arch — Black; Firescreen Arch — New Bronze. Choose and order a compatible model-sized decorative barrier front.

Optional features and accessories

Optional Controls, Remotes and Switches: Wall Switch; Wall Switch Kit with battery backup; Wi-Fi Module for IntelliFire App. Optional compatible control accessory. Wi-Fi requires a module and network; wall switches and battery kits must match the ignition system. Control functions depend on the appliance.

Optional Heat Management: Heat Out; Heat Zone. Optional heat-management component. Heat Out directs heat outdoors; Heat Zone transfers it to another room; Passive Heat uses specified outlets and clearances. Kits, ducts and trims must form an approved system.

Optional Mantel Shelves: Fillmore 72" — Unfinished; Fillmore 72" — Primed; Non-Combustible Cove Gray 60"; Non-Combustible Cove Gray 72"; Non-Combustible Midnight Mist 60"; Non-Combustible Midnight Mist 72"; Non-Combustible Tavern Brown 60"; Non-Combustible Tavern Brown 72"; Non-Combustible Washed Cedar 60"; Non-Combustible Washed Cedar 72"; Non-Combustible Weathered Barnwood 60"; Non-Combustible Weathered Barnwood 72"; Non-Combustible White 60"; Non-Combustible White 72"; Ozark 72" — Primed; Ozark 72" — Distressed Knotty Alder; Ozark 72" — Unfinished. Optional accessory; exact model size, compatibility, quantity and separate charges are confirmed in the quote.

Features & options

Features & options

Review available selections. Included equipment and any additional charges are confirmed on your quote.

Required fuel configuration

(required)

Other selections

  • Natural gas
  • Propane — listed configuration or certified conversion

Match the appliance rating plate. Any required certified conversion kit is separately quoted.

Included Controls, Remotes and Switches

RC400 remote — official illustration for Heirloom 50; shown size or finish may vary
Remote Touchscreen Included

Touchscreen remote is included. Available functions depend on the installed equipment.

Touchscreen remote is included. Available functions depend on the installed equipment.

Optional Controls, Remotes and Switches

Fire is just a flip of the switch away with this simple, single mode function wireless wall switch featuring battery strength indicator, automatic battery backup, on/off. — official illustration for Heirloom 50; shown size or finish may vary
Wall Switch Optional

Optional compatible control accessory. Wi-Fi requires a module and network; wall switches and battery kits must match the ignition system. Control functions depend on the appliance.

Wall Switch Kit with battery backup — official illustration for Heirloom 50; shown size or finish may vary
Wall Switch Kit with battery backup Optional

Optional compatible control accessory. Wi-Fi requires a module and network; wall switches and battery kits must match the ignition system. Control functions depend on the appliance.

Google Home and iPhone combo IntelliFire App Multi-brand — official illustration for Heirloom 50; shown size or finish may vary
Wi-Fi Module for IntelliFire App Optional

Optional compatible control accessory. Wi-Fi requires a module and network; wall switches and battery kits must match the ignition system. Control functions depend on the appliance.

Optional compatible control accessory. Wi-Fi requires a module and network; wall switches and battery kits must match the ignition system. Control functions depend on the appliance.

Required Decorative Interior panels

(required)

HTL-refractory-Heirloom-Herringbone — official illustration for Heirloom 50; shown size or finish may vary
Herringbone Required separately

Choose the Herringbone or Traditional factory configuration. One matching interior is included with that configuration.

HTL-refractory-Heirloom-Traditional — official illustration for Heirloom 50; shown size or finish may vary
Traditional Required separately

Choose the Herringbone or Traditional factory configuration. One matching interior is included with that configuration.

Choose the Herringbone or Traditional factory configuration. One matching interior is included with that configuration.

Required Fronts and Doors

(required)

Front image for True fireplace — official illustration for Heirloom 50; shown size or finish may vary
Firescreen — Black Required separately

Choose and order a compatible model-sized decorative barrier front.

Black finish swatch for Firescreen
Black finish Required separately

Manufacturer finish sample; actual material and screen color may differ.

Front image for True fireplace — official illustration for Heirloom 50; shown size or finish may vary
Firescreen — New Bronze Required separately

Choose and order a compatible model-sized decorative barrier front.

New Bronze finish swatch for Firescreen
New Bronze finish Required separately

Manufacturer finish sample; actual material and screen color may differ.

Front image for True fireplace — official illustration for Heirloom 50; shown size or finish may vary
Firescreen Arch — Black Required separately

Choose and order a compatible model-sized decorative barrier front.

Black finish swatch for Firescreen Arch
Black finish Required separately

Manufacturer finish sample; actual material and screen color may differ.

Front image for True fireplace — official illustration for Heirloom 50; shown size or finish may vary
Firescreen Arch — New Bronze Required separately

Choose and order a compatible model-sized decorative barrier front.

New Bronze finish swatch for Firescreen Arch
New Bronze finish Required separately

Manufacturer finish sample; actual material and screen color may differ.

Choose and order a compatible model-sized decorative barrier front.

Optional Heat Management

Heat Out — official illustration for Heirloom 50; shown size or finish may vary
Heat Out Optional

Optional heat-management component. Heat Out directs heat outdoors; Heat Zone transfers it to another room; Passive Heat uses specified outlets and clearances. Kits, ducts and trims must form an approved system.

Heat Zone — official illustration for Heirloom 50; shown size or finish may vary
Heat Zone Optional

Optional heat-management component. Heat Out directs heat outdoors; Heat Zone transfers it to another room; Passive Heat uses specified outlets and clearances. Kits, ducts and trims must form an approved system.

Optional heat-management component. Heat Out directs heat outdoors; Heat Zone transfers it to another room; Passive Heat uses specified outlets and clearances. Kits, ducts and trims must form an approved system.

Optional Mantel Shelves

Fillmore Mantel Shelf — official illustration for Heirloom 50; shown size or finish may vary
Fillmore 72" — Unfinished Optional

Optional accessory; exact model size, compatibility, quantity and separate charges are confirmed in the quote.

Unfinished finish swatch for Fillmore 72"
Unfinished finish Optional

Manufacturer finish sample; actual material and screen color may differ.

Fillmore Mantel Shelf — official illustration for Heirloom 50; shown size or finish may vary
Fillmore 72" — Primed Optional

Optional accessory; exact model size, compatibility, quantity and separate charges are confirmed in the quote.

Primed finish swatch for Fillmore 72"
Primed finish Optional

Manufacturer finish sample; actual material and screen color may differ.

Non-com cement Mantel price point image — official illustration for Heirloom 50; shown size or finish may vary
Non-Combustible Cove Gray 60" Optional

Optional accessory; exact model size, compatibility, quantity and separate charges are confirmed in the quote.

Non-com cement Mantel price point image — official illustration for Heirloom 50; shown size or finish may vary
Non-Combustible Cove Gray 72" Optional

Optional accessory; exact model size, compatibility, quantity and separate charges are confirmed in the quote.

Non-com cement Mantel price point image — official illustration for Heirloom 50; shown size or finish may vary
Non-Combustible Midnight Mist 60" Optional

Optional accessory; exact model size, compatibility, quantity and separate charges are confirmed in the quote.

Non-com cement Mantel price point image — official illustration for Heirloom 50; shown size or finish may vary
Non-Combustible Midnight Mist 72" Optional

Optional accessory; exact model size, compatibility, quantity and separate charges are confirmed in the quote.

Non-com cement Mantel price point image — official illustration for Heirloom 50; shown size or finish may vary
Non-Combustible Tavern Brown 60" Optional

Optional accessory; exact model size, compatibility, quantity and separate charges are confirmed in the quote.

Non-com cement Mantel price point image — official illustration for Heirloom 50; shown size or finish may vary
Non-Combustible Tavern Brown 72" Optional

Optional accessory; exact model size, compatibility, quantity and separate charges are confirmed in the quote.

Non-com cement Mantel price point image — official illustration for Heirloom 50; shown size or finish may vary
Non-Combustible Washed Cedar 60" Optional

Optional accessory; exact model size, compatibility, quantity and separate charges are confirmed in the quote.

Non-com cement Mantel price point image — official illustration for Heirloom 50; shown size or finish may vary
Non-Combustible Washed Cedar 72" Optional

Optional accessory; exact model size, compatibility, quantity and separate charges are confirmed in the quote.

Non-com cement Mantel price point image — official illustration for Heirloom 50; shown size or finish may vary
Non-Combustible Weathered Barnwood 60" Optional

Optional accessory; exact model size, compatibility, quantity and separate charges are confirmed in the quote.

Non-com cement Mantel price point image — official illustration for Heirloom 50; shown size or finish may vary
Non-Combustible Weathered Barnwood 72" Optional

Optional accessory; exact model size, compatibility, quantity and separate charges are confirmed in the quote.

Non-com cement Mantel price point image — official illustration for Heirloom 50; shown size or finish may vary
Non-Combustible White 60" Optional

Optional accessory; exact model size, compatibility, quantity and separate charges are confirmed in the quote.

Non-com cement Mantel price point image — official illustration for Heirloom 50; shown size or finish may vary
Non-Combustible White 72" Optional

Optional accessory; exact model size, compatibility, quantity and separate charges are confirmed in the quote.

Ozark mantel shelf — official illustration for Heirloom 50; shown size or finish may vary
Ozark 72" — Primed Optional

Optional accessory; exact model size, compatibility, quantity and separate charges are confirmed in the quote.

Primed finish swatch for Ozark 72"
Primed finish Optional

Manufacturer finish sample; actual material and screen color may differ.

Ozark mantel shelf — official illustration for Heirloom 50; shown size or finish may vary
Ozark 72" — Distressed Knotty Alder Optional

Optional accessory; exact model size, compatibility, quantity and separate charges are confirmed in the quote.

Distressed Knotty Alder finish swatch for Ozark 72"
Distressed Knotty Alder finish Optional

Manufacturer finish sample; actual material and screen color may differ.

Ozark mantel shelf — official illustration for Heirloom 50; shown size or finish may vary
Ozark 72" — Unfinished Optional

Optional accessory; exact model size, compatibility, quantity and separate charges are confirmed in the quote.

Unfinished finish swatch for Ozark 72"
Unfinished finish Optional

Manufacturer finish sample; actual material and screen color may differ.

Optional accessory; exact model size, compatibility, quantity and separate charges are confirmed in the quote.

Technical notes

Reflective black glass is an optional interior on the 36- and 42-inch sizes only.

Confirm the required components for an arched-front installation in the quote.

For indoor installation by a qualified hearth installer. Match the fuel, rating plate and model revision. Input is not delivered room heat; altitude, venting and fuel affect performance.

Planning framing dimensions are not a complete clearance schedule. The current installation manual governs the vent route, terminations, mantels, facing, enclosure and combustibles.

Manufacturer gallery and accessory photos may show a different size in this series and optional fronts, panels, media, mantels or heat-management components. They are not all included.

Battery-backup ignition does not supply household power for fans, lights, Wi-Fi or powered venting.
