Capacity
Total Oven Capacity (cu. ft.):
6.9
Upper Oven Capacity (cu. ft.):
2.6
Lower Oven Capacity (cu. ft.):
4.3
Appearance
Handle/Knobs:
Stainless Steel
Oven Door Feature:
WideView™ Window
Cooktop
Burner/BTU - Left Rear:
9100 / 9100
Burner/BTU - Right Rear:
5000 / 5000
Burner/BTU - Left Front:
12000 / 10000
Burner/BTU - Right Front:
18500 / 12500 (UltraHeat™)
Center (Warming Zone) (BTU):
10000 / 10000 (Oval)
Burner Simmer / BTU - Left Rear:
1100
Burner Simmer / BTU - Right Rear:
650
Burner Simmer / BTU - Left Front:
1200
Burner Simmer / BTU - Right Front:
1330
Center (Warming Zone):
2300
Cooktop Finish:
Stainless Steel
Upper Oven Features
Broil Element (BTU/h):
14,500 / 12,500 (LNG/LPG)
Bake Element (BTU/h):
14,500 / 12,500 (LNG/LPG)
Oven Cooking:
Conventional
Oven Cooking Modes:
Bake, Broil, Delay Bake, Delay Clean, Pizza
Oven Control Features:
Glass Touch (SmoothTouch™) and Control Knob
GoCook Smart Oven Light:
Yes (1 Light)
Automatic Safety Shut-Down:
After 12 hours
Lower Oven Features
Convection Burner (BTU/h):
14,000 / 12,000 (LNG/LPG)
Convection Conversion:
Yes
Convection System/Mode/Cooking System:
ProBake Convection®
Oven Cooking Modes:
Bake, Convection Bake, Convection Roast, Favorites, Delay Bake, Delay Clean, Proof, Warm
Oven Control Features:
Glass Touch (SmoothTouch™)
GoCook Smart Oven Light:
Yes (1 Light)
Automatic Safety Shut-Down:
After 12 hours
Control
Cooktop Control Type:
Front Tilt-Control Knobs
Oven Control Type:
Glass Touch (SmoothTouch™) and Control Knob
Clock:
12 hr. or 24 hr. (option)
Temperature Unit of Measure:
Fahrenheit / Celsius
Cooking Complete Reminder Volume:
Beeper
SmartThinQ®
Dimensions/Clearances/Weight
Shipping Weight (lb.):
280
Product Weight (lb.):
225
Overall Depth - including Handle:
28 15/16"
Overall Height - including Back guard:
37 7/8"
Oven Interior Dimensions (Upper) (W x H x D):
24 13/16" x 9 1/4" x 20"
Oven Interior Dimensions (Lower) (W x H x D):
24 13/16" x 14 1/4" x 20"
Height to Cooking Surface:
36"
Carton Dimensions (W x H x D):
31 31/32" x 51" x 30 17/32"
Power/Ratings
Requirements:
120 VAC
Features
5 Sealed Burners
- Expand your options with five cooktop burners that let you sauté, simmer, boil, and more-all at the same time.
- Continuous heavy-duty grates provide a flat cooking surface over the gas burners to keep cookware stable and make it easy to slide pans from burner to burner.
6.9 Cu. Ft. Total Double Oven Capacity
- Whether you're baking large batches of cookies or a 20-pound turkey and all the sides for the holidays, the oven can fit all the pots, pans, Dutch ovens, and skillets you need to get your cook on.
ProBake Convection®
- Delivers even baking results on every rack, every time. The heating element is located on the back wall for optimal heat distribution.
EasyClean®
- In 10 quick minutes your oven can be sparkling clean, without strong chemical fumes or high heat.
SmoothTouch™
- Glass-touch oven controls have a sleek design and are easy to use.
WideView™ Window
- Get a better view of your meals as they cook.
Wi-Fi Connectivity with SmartThinQ® Technology
- LG SmartThinQ® appliances take innovative smart home technology to new heights, changing the way you run your home and your life.
Amazon Alexa
- Control compatible smart appliances with Amazon Alexa. Simply speak your commands and Alexa will do the work for you.
Google Home
- Control compatible smart appliances with Google Home. Simply speak your commands and your Google Home will do the task for you.
Remote Monitoring
- Keep track of what's in the fridge from your grocer's aisle, how much time is left on that roast in the oven, or if it's time to add the next load of laundry right from your smart device. Remote Monitoring will always keep you in the know
Remote Control
- Use your smart device as a remote control to control appliance functions, whether you're home, in the office, or on the road.
SmartDiagnosis™
- The SmartDiagnosis feature helps the service center diagnose problems with the range right over the phone, or with a simple app on your smart phone, helping you minimize costly, inconvenient service calls.
